LLM之RAG实战（五十一）| 使用python和Cypher解析PDF数据，并加载到Neo4j数据库

ArronAI
ArronAI
数据库
向量数据库关系型数据库NoSQL数据库

picture.image

一、必备条件：

  • python语言

  • Neo4j数据库

  • python库： neo4j、llmsherpa、glob、dotenv

二、代码：



from llmsherpa.readers import LayoutPDFReader

from neo4j import GraphDatabase

import uuid

import hashlib

import os

import glob

from datetime import datetime

import time

from dotenv import load_dotenv



# Load environment variables

path = "/home/QA/Neo4j_Stage1/.env"

load_dotenv(path)



# Neo4j configuration

NEO4J_URL = os.environ["NEO4J_URI"]

NEO4J_USER = "neo4j"

NEO4J_PASSWORD = os.environ["NEO4J_PASSWORD"]

NEO4J_DATABASE = "neo4j"



# File location for PDFs

file_location = '/home/QA/Neo4j_Stage1/PDFs'



# Initialize Neo4j

def initialiseNeo4j():

    cypher_schema = [

        "CREATE CONSTRAINT sectionKey IF NOT EXISTS FOR (c:Section) REQUIRE (c.key) IS UNIQUE;",

        "CREATE CONSTRAINT chunkKey IF NOT EXISTS FOR (c:Chunk) REQUIRE (c.key) IS UNIQUE;",

        "CREATE CONSTRAINT documentKey IF NOT EXISTS FOR (c:Document) REQUIRE (c.url_hash) IS UNIQUE;",

        "CREATE CONSTRAINT tableKey IF NOT EXISTS FOR (c:Table) REQUIRE (c.key) IS UNIQUE;",

        "CALL db.index.vector.createNodeIndex('chunkVectorIndex', 'Embedding', 'value', 1536, 'COSINE');"

    ]



    driver = GraphDatabase.driver(NEO4J_URL, database=NEO4J_DATABASE, auth=(NEO4J_USER, NEO4J_PASSWORD))

    with driver.session() as session:

        for cypher in cypher_schema:

            session.run(cypher)

    driver.close()



# Ingest document into Neo4j

def ingestDocumentNeo4j(doc, doc_location):

    cypher_pool = [

        "MERGE (d:Document {name: $doc_name_val}) ON CREATE SET d.url = $doc_url_val RETURN d;",

        "MERGE (p:Section {key: $doc_name_val+'|'+$block_idx_val+'|'+$title_hash_val}) ON CREATE SET p.page_idx = $page_idx_val, p.title_hash = $title_hash_val, p.block_idx = $block_idx_val, p.title = $title_val, p.tag = $tag_val, p.level = $level_val RETURN p;",

        "MATCH (d:Document {name: $doc_name_val}) MATCH (s:Section {key: $doc_name_val+'|'+$block_idx_val+'|'+$title_hash_val}) MERGE (d)<-[:HAS_DOCUMENT]-(s);",

        "MATCH (s1:Section {key: $doc_name_val+'|'+$parent_block_idx_val+'|'+$parent_title_hash_val}) MATCH (s2:Section {key: $doc_name_val+'|'+$block_idx_val+'|'+$title_hash_val}) MERGE (s1)<-[:UNDER_SECTION]-(s2);",

        "MERGE (c:Chunk {key: $doc_name_val+'|'+$block_idx_val+'|'+$sentences_hash_val}) ON CREATE SET c.sentences = $sentences_val, c.sentences_hash = $sentences_hash_val, c.block_idx = $block_idx_val, c.page_idx = $page_idx_val, c.tag = $tag_val, c.level = $level_val RETURN c;",

        "MATCH (c:Chunk {key: $doc_name_val+'|'+$block_idx_val+'|'+$sentences_hash_val}) MATCH (s:Section {key:$doc_name_val+'|'+$parent_block_idx_val+'|'+$parent_hash_val}) MERGE (s)<-[:HAS_PARENT]-(c);",

        "MERGE (t:Table {key: $doc_name_val+'|'+$block_idx_val+'|'+$name_val}) ON CREATE SET t.name = $name_val, t.doc_name = $doc_name_val, t.block_idx = $block_idx_val, t.page_idx = $page_idx_val, t.html = $html_val, t.rows = $rows_val RETURN t;",

        "MATCH (t:Table {key: $doc_name_val+'|'+$block_idx_val+'|'+$name_val}) MATCH (s:Section {key: $doc_name_val+'|'+$parent_block_idx_val+'|'+$parent_hash_val}) MERGE (s)<-[:HAS_PARENT]-(t);",

        "MATCH (t:Table {key: $doc_name_val+'|'+$block_idx_val+'|'+$name_val}) MATCH (s:Document {name: $doc_name_val}) MERGE (s)<-[:HAS_PARENT]-(t);"

    ]



    driver = GraphDatabase.driver(NEO4J_URL, database=NEO4J_DATABASE, auth=(NEO4J_USER, NEO4J_PASSWORD))

    with driver.session() as session:

        doc_name_val = os.path.basename(doc_location)

        doc_url_val = doc_location

        cypher = cypher_pool[0]

        session.run(cypher, doc_name_val=doc_name_val, doc_url_val=doc_url_val)



        for sec in doc.sections():

            sec_title_val = sec.title

            sec_title_hash_val = hashlib.md5(sec_title_val.encode("utf-8")).hexdigest()

            sec_tag_val = sec.tag

            sec_level_val = sec.level

            sec_page_idx_val = sec.page_idx

            sec_block_idx_val = sec.block_idx



            if sec_tag_val != 'table':

                cypher = cypher_pool[1]

                session.run(cypher, page_idx_val=sec_page_idx_val, title_hash_val=sec_title_hash_val, title_val=sec_title_val, tag_val=sec_tag_val, level_val=sec_level_val, block_idx_val=sec_block_idx_val, doc_name_val=doc_name_val)



                sec_parent_val = str(sec.parent.to_text())

                if sec_parent_val == "None":

                    cypher = cypher_pool[2]

                    session.run(cypher, page_idx_val=sec_page_idx_val, title_hash_val=sec_title_hash_val, doc_name_val=doc_name_val, block_idx_val=sec_block_idx_val)

                else:

                    sec_parent_title_hash_val = hashlib.md5(sec_parent_val.encode("utf-8")).hexdigest()

                    sec_parent_page_idx_val = sec.parent.page_idx

                    sec_parent_block_idx_val = sec.parent.block_idx

                    cypher = cypher_pool[3]

                    session.run(cypher, page_idx_val=sec_page_idx_val, title_hash_val=sec_title_hash_val, block_idx_val=sec_block_idx_val, parent_page_idx_val=sec_parent_page_idx_val, parent_title_hash_val=sec_parent_title_hash_val, parent_block_idx_val=sec_parent_block_idx_val, doc_name_val=doc_name_val)



        for chk in doc.chunks():

            chunk_block_idx_val = chk.block_idx

            chunk_page_idx_val = chk.page_idx

            chunk_tag_val = chk.tag

            chunk_level_val = chk.level

            chunk_sentences = "\n".join(chk.sentences)



            if chunk_tag_val != 'table':

                chunk_sentences_hash_val = hashlib.md5(chunk_sentences.encode("utf-8")).hexdigest()

                cypher = cypher_pool[4]

                session.run(cypher, sentences_hash_val=chunk_sentences_hash_val, sentences_val=chunk_sentences, block_idx_val=chunk_block_idx_val, page_idx_val=chunk_page_idx_val, tag_val=chunk_tag_val, level_val=chunk_level_val, doc_name_val=doc_name_val)



                chk_parent_val = str(chk.parent.to_text())

                if chk_parent_val != "None":

                    chk_parent_hash_val = hashlib.md5(chk_parent_val.encode("utf-8")).hexdigest()

                    chk_parent_page_idx_val = chk.parent.page_idx

                    chk_parent_block_idx_val = chk.parent.block_idx

                    cypher = cypher_pool[5]

                    session.run(cypher, sentences_hash_val=chunk_sentences_hash_val, block_idx_val=chunk_block_idx_val, parent_hash_val=chk_parent_hash_val, parent_block_idx_val=chk_parent_block_idx_val, doc_name_val=doc_name_val)



        for tb in doc.tables():

            page_idx_val = tb.page_idx

            block_idx_val = tb.block_idx

            name_val = 'block#' + str(block_idx_val) + '_' + tb.name

            html_val = tb.to_html()

            rows_val = len(tb.rows)

            cypher = cypher_pool[6]

            session.run(cypher, block_idx_val=block_idx_val, page_idx_val=page_idx_val, name_val=name_val, html_val=html_val, rows_val=rows_val, doc_name_val=doc_name_val)



            table_parent_val = str(tb.parent.to_text())

            if table_parent_val != "None":

                table_parent_hash_val = hashlib.md5(table_parent_val.encode("utf-8")).hexdigest()

                table_parent_page_idx_val = tb.parent.page_idx

                table_parent_block_idx_val = tb.parent.block_idx

                cypher = cypher_pool[7]

                session.run(cypher, name_val=name_val, block_idx_val=block_idx_val, parent_page_idx_val=table_parent_page_idx_val, parent_hash_val=table_parent_hash_val, parent_block_idx_val=table_parent_block_idx_val, doc_name_val=doc_name_val)

            else:

                cypher = cypher_pool[8]

                session.run(cypher, name_val=name_val, block_idx_val=block_idx_val, doc_name_val=doc_name_val)



        print(f'\'{doc_name_val}\' Done! Summary: ')

        print('#Sections: ' + str(len(doc.sections())))

        print('#Chunks: ' + str(len(doc.chunks())))

        print('#Tables: ' + str(len(doc.tables())))



    driver.close()



# Parse PDFs and ingest into Neo4j

def parseAndIngestPDFs():

    pdf_files = glob.glob(file_location + '/*.pdf')

    print(f'#PDF files found: {len(pdf_files)}!')



    pdf_reader = LayoutPDFReader("https://readers.llmsherpa.com/api/document/developer/parseDocument?renderFormat=all")



    startTime = datetime.now()



    for pdf_file in pdf_files:

        doc = pdf_reader.read_pdf(pdf_file)

        ingestDocumentNeo4j(doc, pdf_file)



    print(f'Total time: {datetime.now() - startTime}')



# Initialize Neo4j

initialiseNeo4j()



# Parse PDFs and ingest into Neo4j

parseAndIngestPDFs()

三、代码解释

3.1 设置

  • 导入Neo4j环境变量

  • 设置 Neo4j唯一key

3.2 初始化Neo4j

  • 建立与 Neo4j 的连接并创建必要的约束以确保数据完整性。

3.3 提取文档内容

  • 抽取PDFsection、块和表格数据

  • 使用 Cypher 查询在 Neo4j 图形中创建和链接节点

3.4 解析PDF内容

  1. 查找指定目录中的所有 PDF 文件；
  2. 使用 LayoutPDFReader 解析每个 PDF；
  3. 将解析后的 数据 加入到 Neo4j数据库中；
