知识蒸馏有两大类：一类是**「logits蒸馏」** ，另一类是**「特征蒸馏」** 。
「logits蒸馏」 指的是在softmax时使用较高的温度系数，提升负标签的信息，然后使用Student和Teacher在高温softmax下logits的KL散度作为loss。
「中间特征蒸馏」 就是强迫Student去学习Teacher某些中间层的特征，直接匹配中间的特征或学习特征之间的转换关系。例如，在特征No.1和No.2中间，知识可以表示为如何模做两者中间的转化，可以用一个矩阵让学习者产生这个矩阵，学习者和转化之间的学习关系。
这篇文章汇总了常用的知识蒸馏的论文和代码，方便后续的学习和研究。
1、Logits
论文链接：https://proceedings.neurips.cc/paper/2014/file/ea8fcd92d59581717e06eb187f10666d-Paper.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class Logits(nn.Module):
'''
Do Deep Nets Really Need to be Deep?
http://papers.nips.cc/paper/5484-do-deep-nets-really-need-to-be-deep.pdf
'''
def \_\_init\_\_(self):
super(Logits, self).__init__()
def forward(self, out\_s, out\_t):
loss = F.mse_loss(out_s, out_t)
return loss
2、ST
论文链接：https://arxiv.org/pdf/1503.02531.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class SoftTarget(nn.Module):
'''
Distilling the Knowledge in a Neural Network
https://arxiv.org/pdf/1503.02531.pdf
'''
def \_\_init\_\_(self, T):
super(SoftTarget, self).__init__()
self.T = T
def forward(self, out\_s, out\_t):
loss = F.kl_div(F.log_softmax(out_s/self.T, dim=1),
F.softmax(out_t/self.T, dim=1),
reduction='batchmean') * self.T * self.T
return loss
3、AT
论文链接：https://arxiv.org/pdf/1612.03928.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
'''
AT with sum of absolute values with power p
'''
class AT(nn.Module):
'''
Paying More Attention to Attention: Improving the Performance of Convolutional
Neural Netkworks wia Attention Transfer
https://arxiv.org/pdf/1612.03928.pdf
'''
def \_\_init\_\_(self, p):
super(AT, self).__init__()
self.p = p
def forward(self, fm\_s, fm\_t):
loss = F.mse_loss(self.attention_map(fm_s), self.attention_map(fm_t))
return loss
def attention\_map(self, fm, eps=1e-6):
am = torch.pow(torch.abs(fm), self.p)
am = torch.sum(am, dim=1, keepdim=True)
norm = torch.norm(am, dim=(2,3), keepdim=True)
am = torch.div(am, norm+eps)
return am
4、Fitnet
论文链接：https://arxiv.org/pdf/1412.6550.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class Hint(nn.Module):
'''
FitNets: Hints for Thin Deep Nets
https://arxiv.org/pdf/1412.6550.pdf
'''
def \_\_init\_\_(self):
super(Hint, self).__init__()
def forward(self, fm\_s, fm\_t):
loss = F.mse_loss(fm_s, fm_t)
return loss
5、NST
论文链接：https://arxiv.org/pdf/1707.0121
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
'''
NST with Polynomial Kernel, where d=2 and c=0
'''
class NST(nn.Module):
'''
Like What You Like: Knowledge Distill via Neuron Selectivity Transfer
https://arxiv.org/pdf/1707.01219.pdf
'''
def \_\_init\_\_(self):
super(NST, self).__init__()
def forward(self, fm\_s, fm\_t):
fm_s = fm_s.view(fm_s.size(0), fm_s.size(1), -1)
fm_s = F.normalize(fm_s, dim=2)
fm_t = fm_t.view(fm_t.size(0), fm_t.size(1), -1)
fm_t = F.normalize(fm_t, dim=2)
loss = self.poly_kernel(fm_t, fm_t).mean() \
+ self.poly_kernel(fm_s, fm_s).mean() \
- 2 * self.poly_kernel(fm_s, fm_t).mean()
return loss
def poly\_kernel(self, fm1, fm2):
fm1 = fm1.unsqueeze(1)
fm2 = fm2.unsqueeze(2)
out = (fm1 * fm2).sum(-1).pow(2)
return out
6、PKT
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
'''
Adopted from https://github.com/passalis/probabilistic\_kt/blob/master/nn/pkt.py
'''
class PKTCosSim(nn.Module):
'''
Learning Deep Representations with Probabilistic Knowledge Transfer
http://openaccess.thecvf.com/content\_ECCV\_2018/papers/Nikolaos\_Passalis\_Learning\_Deep\_Representations\_ECCV\_2018\_paper.pdf
'''
def \_\_init\_\_(self):
super(PKTCosSim, self).__init__()
def forward(self, feat\_s, feat\_t, eps=1e-6):
# Normalize each vector by its norm
feat_s_norm = torch.sqrt(torch.sum(feat_s ** 2, dim=1, keepdim=True))
feat_s = feat_s / (feat_s_norm + eps)
feat_s[feat_s != feat_s] = 0
feat_t_norm = torch.sqrt(torch.sum(feat_t ** 2, dim=1, keepdim=True))
feat_t = feat_t / (feat_t_norm + eps)
feat_t[feat_t != feat_t] = 0
# Calculate the cosine similarity
feat_s_cos_sim = torch.mm(feat_s, feat_s.transpose(0, 1))
feat_t_cos_sim = torch.mm(feat_t, feat_t.transpose(0, 1))
# Scale cosine similarity to [0,1]
feat_s_cos_sim = (feat_s_cos_sim + 1.0) / 2.0
feat_t_cos_sim = (feat_t_cos_sim + 1.0) / 2.0
# Transform them into probabilities
feat_s_cond_prob = feat_s_cos_sim / torch.sum(feat_s_cos_sim, dim=1, keepdim=True)
feat_t_cond_prob = feat_t_cos_sim / torch.sum(feat_t_cos_sim, dim=1, keepdim=True)
# Calculate the KL-divergence
loss = torch.mean(feat_t_cond_prob * torch.log((feat_t_cond_prob + eps) / (feat_s_cond_prob + eps)))
return loss
7、FSP
论文链接：http://openaccess.thecvf.com/content\_cvpr\_2017/papers/Yim\_A\_Gift\_From\_CVPR\_2017\_paper.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class FSP(nn.Module):
'''
A Gift from Knowledge Distillation: Fast Optimization, Network Minimization and Transfer Learning
http://openaccess.thecvf.com/content\_cvpr\_2017/papers/Yim\_A\_Gift\_From\_CVPR\_2017\_paper.pdf
'''
def \_\_init\_\_(self):
super(FSP, self).__init__()
def forward(self, fm\_s1, fm\_s2, fm\_t1, fm\_t2):
loss = F.mse_loss(self.fsp_matrix(fm_s1,fm_s2), self.fsp_matrix(fm_t1,fm_t2))
return loss
def fsp\_matrix(self, fm1, fm2):
if fm1.size(2) > fm2.size(2):
fm1 = F.adaptive_avg_pool2d(fm1, (fm2.size(2), fm2.size(3)))
fm1 = fm1.view(fm1.size(0), fm1.size(1), -1)
fm2 = fm2.view(fm2.size(0), fm2.size(1), -1).transpose(1,2)
fsp = torch.bmm(fm1, fm2) / fm1.size(2)
return fsp
8、FT
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class FT(nn.Module):
'''
araphrasing Complex Network: Network Compression via Factor Transfer
http://papers.nips.cc/paper/7541-paraphrasing-complex-network-network-compression-via-factor-transfer.pdf
'''
def \_\_init\_\_(self):
super(FT, self).__init__()
def forward(self, factor\_s, factor\_t):
loss = F.l1_loss(self.normalize(factor_s), self.normalize(factor_t))
return loss
def normalize(self, factor):
norm_factor = F.normalize(factor.view(factor.size(0),-1))
return norm_factor
9、RKD
论文链接：https://arxiv.org/pdf/1904.05068.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
'''
From https://github.com/lenscloth/RKD/blob/master/metric/loss.py
'''
class RKD(nn.Module):
'''
Relational Knowledge Distillation
https://arxiv.org/pdf/1904.05068.pdf
'''
def \_\_init\_\_(self, w\_dist, w\_angle):
super(RKD, self).__init__()
self.w_dist = w_dist
self.w_angle = w_angle
def forward(self, feat\_s, feat\_t):
loss = self.w_dist * self.rkd_dist(feat_s, feat_t) + \
self.w_angle * self.rkd_angle(feat_s, feat_t)
return loss
def rkd\_dist(self, feat\_s, feat\_t):
feat_t_dist = self.pdist(feat_t, squared=False)
mean_feat_t_dist = feat_t_dist[feat_t_dist>0].mean()
feat_t_dist = feat_t_dist / mean_feat_t_dist
feat_s_dist = self.pdist(feat_s, squared=False)
mean_feat_s_dist = feat_s_dist[feat_s_dist>0].mean()
feat_s_dist = feat_s_dist / mean_feat_s_dist
loss = F.smooth_l1_loss(feat_s_dist, feat_t_dist)
return loss
def rkd\_angle(self, feat\_s, feat\_t):
# N x C --> N x N x C
feat_t_vd = (feat_t.unsqueeze(0) - feat_t.unsqueeze(1))
norm_feat_t_vd = F.normalize(feat_t_vd, p=2, dim=2)
feat_t_angle = torch.bmm(norm_feat_t_vd, norm_feat_t_vd.transpose(1, 2)).view(-1)
feat_s_vd = (feat_s.unsqueeze(0) - feat_s.unsqueeze(1))
norm_feat_s_vd = F.normalize(feat_s_vd, p=2, dim=2)
feat_s_angle = torch.bmm(norm_feat_s_vd, norm_feat_s_vd.transpose(1, 2)).view(-1)
loss = F.smooth_l1_loss(feat_s_angle, feat_t_angle)
return loss
def pdist(self, feat, squared=False, eps=1e-12):
feat_square = feat.pow(2).sum(dim=1)
feat_prod = torch.mm(feat, feat.t())
feat_dist = (feat_square.unsqueeze(0) + feat_square.unsqueeze(1) - 2 * feat_prod).clamp(min=eps)
if not squared:
feat_dist = feat_dist.sqrt()
feat_dist = feat_dist.clone()
feat_dist[range(len(feat)), range(len(feat))] = 0
return feat_dist
10、AB
论文链接：https://arxiv.org/pdf/1811.03233.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class AB(nn.Module):
'''
Knowledge Transfer via Distillation of Activation Boundaries Formed by Hidden Neurons
https://arxiv.org/pdf/1811.03233.pdf
'''
def \_\_init\_\_(self, margin):
super(AB, self).__init__()
self.margin = margin
def forward(self, fm\_s, fm\_t):
# fm befor activation
loss = ((fm_s + self.margin).pow(2) * ((fm_s > -self.margin) & (fm_t <= 0)).float() +
(fm_s - self.margin).pow(2) * ((fm_s <= self.margin) & (fm_t > 0)).float())
loss = loss.mean()
return loss
11、SP
论文链接：https://arxiv.org/pdf/1907.09682.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class SP(nn.Module):
'''
Similarity-Preserving Knowledge Distillation
https://arxiv.org/pdf/1907.09682.pdf
'''
def \_\_init\_\_(self):
super(SP, self).__init__()
def forward(self, fm\_s, fm\_t):
fm_s = fm_s.view(fm_s.size(0), -1)
G_s = torch.mm(fm_s, fm_s.t())
norm_G_s = F.normalize(G_s, p=2, dim=1)
fm_t = fm_t.view(fm_t.size(0), -1)
G_t = torch.mm(fm_t, fm_t.t())
norm_G_t = F.normalize(G_t, p=2, dim=1)
loss = F.mse_loss(norm_G_s, norm_G_t)
return loss
12、Sobolev
论文链接：https://arxiv.org/pdf/1706.04859.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
from torch.autograd import grad
class Sobolev(nn.Module):
'''
Sobolev Training for Neural Networks
https://arxiv.org/pdf/1706.04859.pdf
Knowledge Transfer with Jacobian Matching
http://de.arxiv.org/pdf/1803.00443
'''
def \_\_init\_\_(self):
super(Sobolev, self).__init__()
def forward(self, out\_s, out\_t, img, target):
target_out_s = torch.gather(out_s, 1, target.view(-1, 1))
grad_s = grad(outputs=target_out_s, inputs=img,
grad_outputs=torch.ones_like(target_out_s),
create_graph=True, retain_graph=True, only_inputs=True)[0]
norm_grad_s = F.normalize(grad_s.view(grad_s.size(0), -1), p=2, dim=1)
target_out_t = torch.gather(out_t, 1, target.view(-1, 1))
grad_t = grad(outputs=target_out_t, inputs=img,
grad_outputs=torch.ones_like(target_out_t),
create_graph=True, retain_graph=True, only_inputs=True)[0]
norm_grad_t = F.normalize(grad_t.view(grad_t.size(0), -1), p=2, dim=1)
loss = F.mse_loss(norm_grad_s, norm_grad_t.detach())
return loss
13、BSS
论文链接：https://arxiv.org/pdf/1805.05532.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
from torch.autograd.gradcheck import zero_gradients
'''
Modified by https://github.com/bhheo/BSS\_distillation
'''
def reduce\_sum(x, keepdim=True):
for d in reversed(range(1, x.dim())):
x = x.sum(d, keepdim=keepdim)
return x
def l2\_norm(x, keepdim=True):
norm = reduce_sum(x*x, keepdim=keepdim)
return norm.sqrt()
class BSS(nn.Module):
'''
Knowledge Distillation with Adversarial Samples Supporting Decision Boundary
https://arxiv.org/pdf/1805.05532.pdf
'''
def \_\_init\_\_(self, T):
super(BSS, self).__init__()
self.T = T
def forward(self, attacked\_out\_s, attacked\_out\_t):
loss = F.kl_div(F.log_softmax(attacked_out_s/self.T, dim=1),
F.softmax(attacked_out_t/self.T, dim=1),
reduction='batchmean') #* self.T * self.T
return loss
class BSSAttacker():
def \_\_init\_\_(self, step\_alpha, num\_steps, eps=1e-4):
self.step_alpha = step_alpha
self.num_steps = num_steps
self.eps = eps
def attack(self, model, img, target, attack\_class):
img = img.detach().requires_grad_(True)
step = 0
while step < self.num_steps:
zero_gradients(img)
_, _, _, _, _, output = model(img)
score = F.softmax(output, dim=1)
score_target = score.gather(1, target.unsqueeze(1))
score_attack_class = score.gather(1, attack_class.unsqueeze(1))
loss = (score_attack_class - score_target).sum()
loss.backward()
step_alpha = self.step_alpha * (target == output.max(1)[1]).float()
step_alpha = step_alpha.unsqueeze(1).unsqueeze(1).unsqueeze(1)
if step_alpha.sum() == 0:
break
pert = (score_target - score_attack_class).unsqueeze(1).unsqueeze(1)
norm_pert = step_alpha * (pert + self.eps) * img.grad / l2_norm(img.grad)
step_adv = img + norm_pert
step_adv = torch.clamp(step_adv, -2.5, 2.5)
img.data = step_adv.data
step += 1
return img
14、CC
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
import math
'''
CC with P-order Taylor Expansion of Gaussian RBF kernel
'''
class CC(nn.Module):
'''
Correlation Congruence for Knowledge Distillation
http://openaccess.thecvf.com/content\_ICCV\_2019/papers/
Peng\_Correlation\_Congruence\_for\_Knowledge\_Distillation\_ICCV\_2019\_paper.pdf
'''
def \_\_init\_\_(self, gamma, P\_order):
super(CC, self).__init__()
self.gamma = gamma
self.P_order = P_order
def forward(self, feat\_s, feat\_t):
corr_mat_s = self.get_correlation_matrix(feat_s)
corr_mat_t = self.get_correlation_matrix(feat_t)
loss = F.mse_loss(corr_mat_s, corr_mat_t)
return loss
def get\_correlation\_matrix(self, feat):
feat = F.normalize(feat, p=2, dim=-1)
sim_mat = torch.matmul(feat, feat.t())
corr_mat = torch.zeros_like(sim_mat)
for p in range(self.P_order+1):
corr_mat += math.exp(-2*self.gamma) * (2*self.gamma)**p / \
math.factorial(p) * torch.pow(sim_mat, p)
return corr_mat
15、LwM
论文链接：https://arxiv.org/pdf/1811.08051.pdf
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
from torch.autograd import grad
'''
LwM is originally an incremental learning method with
classification/distillation/attention distillation losses.
Here, LwM is only defined as the Grad-CAM based attention distillation.
'''
class LwM(nn.Module):
'''
Learning without Memorizing
https://arxiv.org/pdf/1811.08051.pdf
'''
def \_\_init\_\_(self):
super(LwM, self).__init__()
def forward(self, out\_s, fm\_s, out\_t, fm\_t, target):
target_out_t = torch.gather(out_t, 1, target.view(-1, 1))
grad_fm_t = grad(outputs=target_out_t, inputs=fm_t,
grad_outputs=torch.ones_like(target_out_t),
create_graph=True, retain_graph=True, only_inputs=True)[0]
weights_t = F.adaptive_avg_pool2d(grad_fm_t, 1)
cam_t = torch.sum(torch.mul(weights_t, grad_fm_t), dim=1, keepdim=True)
cam_t = F.relu(cam_t)
cam_t = cam_t.view(cam_t.size(0), -1)
norm_cam_t = F.normalize(cam_t, p=2, dim=1)
target_out_s = torch.gather(out_s, 1, target.view(-1, 1))
grad_fm_s = grad(outputs=target_out_s, inputs=fm_s,
grad_outputs=torch.ones_like(target_out_s),
create_graph=True, retain_graph=True, only_inputs=True)[0]
weights_s = F.adaptive_avg_pool2d(grad_fm_s, 1)
cam_s = torch.sum(torch.mul(weights_s, grad_fm_s), dim=1, keepdim=True)
cam_s = F.relu(cam_s)
cam_s = cam_s.view(cam_s.size(0), -1)
norm_cam_s = F.normalize(cam_s, p=2, dim=1)
loss = F.l1_loss(norm_cam_s, norm_cam_t.detach())
return loss
16、IRG
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
class IRG(nn.Module):
'''
Knowledge Distillation via Instance Relationship Graph
http://openaccess.thecvf.com/content\_CVPR\_2019/papers/
Liu\_Knowledge\_Distillation\_via\_Instance\_Relationship\_Graph\_CVPR\_2019\_paper.pdf
The official code is written by Caffe
https://github.com/yufanLIU/IRG
'''
def \_\_init\_\_(self, w\_irg\_vert, w\_irg\_edge, w\_irg\_tran):
super(IRG, self).__init__()
self.w_irg_vert = w_irg_vert
self.w_irg_edge = w_irg_edge
self.w_irg_tran = w_irg_tran
def forward(self, irg\_s, irg\_t):
fm_s1, fm_s2, feat_s, out_s = irg_s
fm_t1, fm_t2, feat_t, out_t = irg_t
loss_irg_vert = F.mse_loss(out_s, out_t)
irg_edge_feat_s = self.euclidean_dist_feat(feat_s, squared=True)
irg_edge_feat_t = self.euclidean_dist_feat(feat_t, squared=True)
irg_edge_fm_s1 = self.euclidean_dist_fm(fm_s1, squared=True)
irg_edge_fm_t1 = self.euclidean_dist_fm(fm_t1, squared=True)
irg_edge_fm_s2 = self.euclidean_dist_fm(fm_s2, squared=True)
irg_edge_fm_t2 = self.euclidean_dist_fm(fm_t2, squared=True)
loss_irg_edge = (F.mse_loss(irg_edge_feat_s, irg_edge_feat_t) +
F.mse_loss(irg_edge_fm_s1, irg_edge_fm_t1 ) +
F.mse_loss(irg_edge_fm_s2, irg_edge_fm_t2 )) / 3.0
irg_tran_s = self.euclidean_dist_fms(fm_s1, fm_s2, squared=True)
irg_tran_t = self.euclidean_dist_fms(fm_t1, fm_t2, squared=True)
loss_irg_tran = F.mse_loss(irg_tran_s, irg_tran_t)
# print(self.w\_irg\_vert * loss\_irg\_vert)
# print(self.w\_irg\_edge * loss\_irg\_edge)
# print(self.w\_irg\_tran * loss\_irg\_tran)
# print()
loss = (self.w_irg_vert * loss_irg_vert +
self.w_irg_edge * loss_irg_edge +
self.w_irg_tran * loss_irg_tran)
return loss
def euclidean\_dist\_fms(self, fm1, fm2, squared=False, eps=1e-12):
'''
Calculating the IRG Transformation, where fm1 precedes fm2 in the network.
'''
if fm1.size(2) > fm2.size(2):
fm1 = F.adaptive_avg_pool2d(fm1, (fm2.size(2), fm2.size(3)))
if fm1.size(1) < fm2.size(1):
fm2 = (fm2[:,0::2,:,:] + fm2[:,1::2,:,:]) / 2.0
fm1 = fm1.view(fm1.size(0), -1)
fm2 = fm2.view(fm2.size(0), -1)
fms_dist = torch.sum(torch.pow(fm1-fm2, 2), dim=-1).clamp(min=eps)
if not squared:
fms_dist = fms_dist.sqrt()
fms_dist = fms_dist / fms_dist.max()
return fms_dist
def euclidean\_dist\_fm(self, fm, squared=False, eps=1e-12):
'''
Calculating the IRG edge of feature map.
'''
fm = fm.view(fm.size(0), -1)
fm_square = fm.pow(2).sum(dim=1)
fm_prod = torch.mm(fm, fm.t())
fm_dist = (fm_square.unsqueeze(0) + fm_square.unsqueeze(1) - 2 * fm_prod).clamp(min=eps)
if not squared:
fm_dist = fm_dist.sqrt()
fm_dist = fm_dist.clone()
fm_dist[range(len(fm)), range(len(fm))] = 0
fm_dist = fm_dist / fm_dist.max()
return fm_dist
def euclidean\_dist\_feat(self, feat, squared=False, eps=1e-12):
'''
Calculating the IRG edge of feat.
'''
feat_square = feat.pow(2).sum(dim=1)
feat_prod = torch.mm(feat, feat.t())
feat_dist = (feat_square.unsqueeze(0) + feat_square.unsqueeze(1) - 2 * feat_prod).clamp(min=eps)
if not squared:
feat_dist = feat_dist.sqrt()
feat_dist = feat_dist.clone()
feat_dist[range(len(feat)), range(len(feat))] = 0
feat_dist = feat_dist / feat_dist.max()
return feat_dist
17、VID
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
import numpy as np
def conv1x1(in\_channels, out\_channels):
return nn.Conv2d(in_channels, out_channels,
kernel_size=1, stride=1,
padding=0, bias=False)
'''
Modified from https://github.com/HobbitLong/RepDistiller/blob/master/distiller\_zoo/VID.py
'''
class VID(nn.Module):
'''
Variational Information Distillation for Knowledge Transfer
https://zpascal.net/cvpr2019/Ahn\_Variational\_Information\_Distillation\_for\_Knowledge\_Transfer\_CVPR\_2019\_paper.pdf
'''
def \_\_init\_\_(self, in\_channels, mid\_channels, out\_channels, init\_var, eps=1e-6):
super(VID, self).__init__()
self.eps = eps
self.regressor = nn.Sequential(*[
conv1x1(in_channels, mid_channels),
# nn.BatchNorm2d(mid\_channels),
nn.ReLU(),
conv1x1(mid_channels, mid_channels),
# nn.BatchNorm2d(mid\_channels),
nn.ReLU(),
conv1x1(mid_channels, out_channels),
])
self.alpha = nn.Parameter(
np.log(np.exp(init_var-eps)-1.0) * torch.ones(out_channels)
)
for m in self.modules():
if isinstance(m, nn.Conv2d):
nn.init.kaiming_normal_(m.weight, mode='fan\_out', nonlinearity='relu')
if m.bias is not None:
nn.init.constant_(m.bias, 0)
# elif isinstance(m, nn.BatchNorm2d):
# nn.init.constant\_(m.weight, 1)
# nn.init.constant\_(m.bias, 0)
def forward(self, fm\_s, fm\_t):
pred_mean = self.regressor(fm_s)
pred_var = torch.log(1.0+torch.exp(self.alpha)) + self.eps
pred_var = pred_var.view(1, -1, 1, 1)
neg_log_prob = 0.5 * (torch.log(pred_var) + (pred_mean-fm_t)**2 / pred_var)
loss = torch.mean(neg_log_prob)
return loss
18、OFD
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
import numpy as np
'''
Modified from https://github.com/clovaai/overhaul-distillation/blob/master/CIFAR-100/distiller.py
'''
class OFD(nn.Module):
'''
A Comprehensive Overhaul of Feature Distillation
http://openaccess.thecvf.com/content\_ICCV\_2019/papers/
Heo\_A\_Comprehensive\_Overhaul\_of\_Feature\_Distillation\_ICCV\_2019\_paper.pdf
'''
def \_\_init\_\_(self, in\_channels, out\_channels):
super(OFD, self).__init__()
self.connector = nn.Sequential(*[
nn.Conv2d(in_channels, out_channels, kernel_size=1, stride=1, padding=0, bias=False),
nn.BatchNorm2d(out_channels)
])
for m in self.modules():
if isinstance(m, nn.Conv2d):
nn.init.kaiming_normal_(m.weight, mode='fan\_out', nonlinearity='relu')
if m.bias is not None:
nn.init.constant_(m.bias, 0)
elif isinstance(m, nn.BatchNorm2d):
nn.init.constant_(m.weight, 1)
nn.init.constant_(m.bias, 0)
def forward(self, fm\_s, fm\_t):
margin = self.get_margin(fm_t)
fm_t = torch.max(fm_t, margin)
fm_s = self.connector(fm_s)
mask = 1.0 - ((fm_s <= fm_t) & (fm_t <= 0.0)).float()
loss = torch.mean((fm_s - fm_t)**2 * mask)
return loss
def get\_margin(self, fm, eps=1e-6):
mask = (fm < 0.0).float()
masked_fm = fm * mask
margin = masked_fm.sum(dim=(0,2,3), keepdim=True) / (mask.sum(dim=(0,2,3), keepdim=True)+eps)
return margin
19、AFD
论文链接：https://openreview.net/pdf?id=ryxyCeHtPB
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
import math
'''
In the original paper, AFD is one of components of AFDS.
AFDS: Attention Feature Distillation and Selection
AFD: Attention Feature Distillation
AFS: Attention Feature Selection
We find the original implementation of attention is unstable, thus we replace it with a SE block.
'''
class AFD(nn.Module):
'''
Pay Attention to Features, Transfer Learn Faster CNNs
https://openreview.net/pdf?id=ryxyCeHtPB
'''
def \_\_init\_\_(self, in\_channels, att\_f):
super(AFD, self).__init__()
mid_channels = int(in_channels * att_f)
self.attention = nn.Sequential(*[
nn.Conv2d(in_channels, mid_channels, 1, 1, 0, bias=True),
nn.ReLU(inplace=True),
nn.Conv2d(mid_channels, in_channels, 1, 1, 0, bias=True)
])
for m in self.modules():
if isinstance(m, nn.Conv2d):
nn.init.kaiming_normal_(m.weight, mode='fan\_out', nonlinearity='relu')
if m.bias is not None:
nn.init.constant_(m.bias, 0)
def forward(self, fm\_s, fm\_t, eps=1e-6):
fm_t_pooled = F.adaptive_avg_pool2d(fm_t, 1)
rho = self.attention(fm_t_pooled)
# rho = F.softmax(rho.squeeze(), dim=-1)
rho = torch.sigmoid(rho.squeeze())
rho = rho / torch.sum(rho, dim=1, keepdim=True)
fm_s_norm = torch.norm(fm_s, dim=(2,3), keepdim=True)
fm_s = torch.div(fm_s, fm_s_norm+eps)
fm_t_norm = torch.norm(fm_t, dim=(2,3), keepdim=True)
fm_t = torch.div(fm_t, fm_t_norm+eps)
loss = rho * torch.pow(fm_s-fm_t, 2).mean(dim=(2,3))
loss = loss.sum(1).mean(0)
return loss
20、CRD
论文链接：https://openreview.net/pdf?id=SkgpBJrtvS
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
import math
'''
Modified from https://github.com/HobbitLong/RepDistiller/tree/master/crd
'''
class CRD(nn.Module):
'''
Contrastive Representation Distillation
https://openreview.net/pdf?id=SkgpBJrtvS
includes two symmetric parts:
(a) using teacher as anchor, choose positive and negatives over the student side
(b) using student as anchor, choose positive and negatives over the teacher side
Args:
s\_dim: the dimension of student's feature
t\_dim: the dimension of teacher's feature
feat\_dim: the dimension of the projection space
nce\_n: number of negatives paired with each positive
nce\_t: the temperature
nce\_mom: the momentum for updating the memory buffer
n\_data: the number of samples in the training set, which is the M in Eq.(19)
'''
def \_\_init\_\_(self, s\_dim, t\_dim, feat\_dim, nce\_n, nce\_t, nce\_mom, n\_data):
super(CRD, self).__init__()
self.embed_s = Embed(s_dim, feat_dim)
self.embed_t = Embed(t_dim, feat_dim)
self.contrast = ContrastMemory(feat_dim, n_data, nce_n, nce_t, nce_mom)
self.criterion_s = ContrastLoss(n_data)
self.criterion_t = ContrastLoss(n_data)
def forward(self, feat\_s, feat\_t, idx, sample\_idx):
feat_s = self.embed_s(feat_s)
feat_t = self.embed_t(feat_t)
out_s, out_t = self.contrast(feat_s, feat_t, idx, sample_idx)
loss_s = self.criterion_s(out_s)
loss_t = self.criterion_t(out_t)
loss = loss_s + loss_t
return loss
class Embed(nn.Module):
def \_\_init\_\_(self, in\_dim, out\_dim):
super(Embed, self).__init__()
self.linear = nn.Linear(in_dim, out_dim)
def forward(self, x):
x = x.view(x.size(0), -1)
x = self.linear(x)
x = F.normalize(x, p=2, dim=1)
return x
class ContrastLoss(nn.Module):
'''
contrastive loss, corresponding to Eq.(18)
'''
def \_\_init\_\_(self, n\_data, eps=1e-7):
super(ContrastLoss, self).__init__()
self.n_data = n_data
self.eps = eps
def forward(self, x):
bs = x.size(0)
N = x.size(1) - 1
M = float(self.n_data)
# loss for positive pair
pos_pair = x.select(1, 0)
log_pos = torch.div(pos_pair, pos_pair.add(N / M + self.eps)).log_()
# loss for negative pair
neg_pair = x.narrow(1, 1, N)
log_neg = torch.div(neg_pair.clone().fill_(N / M), neg_pair.add(N / M + self.eps)).log_()
loss = -(log_pos.sum() + log_neg.sum()) / bs
return loss
class ContrastMemory(nn.Module):
def \_\_init\_\_(self, feat\_dim, n\_data, nce\_n, nce\_t, nce\_mom):
super(ContrastMemory, self).__init__()
self.N = nce_n
self.T = nce_t
self.momentum = nce_mom
self.Z_t = None
self.Z_s = None
stdv = 1. / math.sqrt(feat_dim / 3.)
self.register_buffer('memory\_t', torch.rand(n_data, feat_dim).mul_(2 * stdv).add_(-stdv))
self.register_buffer('memory\_s', torch.rand(n_data, feat_dim).mul_(2 * stdv).add_(-stdv))
def forward(self, feat\_s, feat\_t, idx, sample\_idx):
bs = feat_s.size(0)
feat_dim = self.memory_s.size(1)
n_data = self.memory_s.size(0)
# using teacher as anchor
weight_s = torch.index_select(self.memory_s, 0, sample_idx.view(-1)).detach()
weight_s = weight_s.view(bs, self.N + 1, feat_dim)
out_t = torch.bmm(weight_s, feat_t.view(bs, feat_dim, 1))
out_t = torch.exp(torch.div(out_t, self.T)).squeeze().contiguous()
# using student as anchor
weight_t = torch.index_select(self.memory_t, 0, sample_idx.view(-1)).detach()
weight_t = weight_t.view(bs, self.N + 1, feat_dim)
out_s = torch.bmm(weight_t, feat_s.view(bs, feat_dim, 1))
out_s = torch.exp(torch.div(out_s, self.T)).squeeze().contiguous()
# set Z if haven't been set yet
if self.Z_t is None:
self.Z_t = (out_t.mean() * n_data).detach().item()
if self.Z_s is None:
self.Z_s = (out_s.mean() * n_data).detach().item()
out_t = torch.div(out_t, self.Z_t)
out_s = torch.div(out_s, self.Z_s)
# update memory
with torch.no_grad():
pos_mem_t = torch.index_select(self.memory_t, 0, idx.view(-1))
pos_mem_t.mul_(self.momentum)
pos_mem_t.add_(torch.mul(feat_t, 1 - self.momentum))
pos_mem_t = F.normalize(pos_mem_t, p=2, dim=1)
self.memory_t.index_copy_(0, idx, pos_mem_t)
pos_mem_s = torch.index_select(self.memory_s, 0, idx.view(-1))
pos_mem_s.mul_(self.momentum)
pos_mem_s.add_(torch.mul(feat_s, 1 - self.momentum))
pos_mem_s = F.normalize(pos_mem_s, p=2, dim=1)
self.memory_s.index_copy_(0, idx, pos_mem_s)
return out_s, out_t
21、DML
代码：
from __future__ import absolute_import
from __future__ import print_function
from __future__ import division
import torch
import torch.nn as nn
import torch.nn.functional as F
'''
DML with only two networks
'''
class DML(nn.Module):
'''
Deep Mutual Learning
https://zpascal.net/cvpr2018/Zhang\_Deep\_Mutual\_Learning\_CVPR\_2018\_paper.pdf
'''
def \_\_init\_\_(self):
super(DML, self).__init__()
def forward(self, out1, out2):
loss = F.kl_div(F.log_softmax(out1, dim=1),
F.softmax(out2, dim=1),
reduction='batchmean')
return loss
推荐阅读
[
DeepSORT再升级 | Deep OC-SORT引入目标外观信息，大幅领先SOTA](https://mp.weixin.qq.com/s?__biz=MzU5OTA2Mjk5Mw==&mid=2247503628&idx=1&sn=a49dc9f38ff4b4cd71e06d15d9aa7a88&chksm=feb82fb2c9cfa6a456cf9f36da31796862af32b6e1f915e71060c5a77984e615dffc918563f8&scene=21#wechat_redirect)
[
YOLOv8官方支持多目标跟踪 | ByteTrack、BoT-SORT都已加入YOLOv8官方](https://mp.weixin.qq.com/s?__biz=MzU5OTA2Mjk5Mw==&mid=2247503531&idx=1&sn=d0b69f7c5bbb79c502b906372028136e&chksm=feb82e15c9cfa703c1c3eb0c512975078282f1b83a9f9e38d4c995037efd6b4a990975e6de55&scene=21#wechat_redirect)
[
YOLOv5抛弃Anchor-Base方法 | YOLOv5u正式加入Anchor-Free大家庭](https://mp.weixin.qq.com/s?__biz=MzU5OTA2Mjk5Mw==&mid=2247503230&idx=1&sn=0a986d9a50db9cf9e47469d88ae8596f&chksm=feb82dc0c9cfa4d6f38f165755332497d595e99d0fb95350ef209859c4cd495e171bc809a804&scene=21#wechat_redirect)
扫码加入👉「集智书童-模型蒸馏」交流群
（备注： 方向+学校/公司+昵称 ）
想要了解更多：
前沿AI视觉感知全栈知识👉「分类、检测、分割、关键点、车道线检测、3D视觉（分割、检测）、多模态、目标跟踪、NerF」
行业技术方案 👉「AI安防、AI医疗、AI自动驾驶」
AI模型部署落地实战 👉「CUDA、TensorRT、NCNN、OpenVINO、MNN、ONNXRuntime以及地平线框架」
欢迎扫描上方二维码，加入「 集智书童-知识星球 」，日常分享论文、学习笔记、问题解决方案、部署方案以及全栈式答疑，期待交流！
免责声明
凡本公众号注明“来源：XXX（非集智书童）”的作品，均转载自其它媒体，版权归原作者所有，如有侵权请联系我们删除，谢谢。
点击下方“ 阅读原文 ”，
了解更多AI学习路上的 「武功秘籍」
